50138446
LE23/2
LE23/2 - Throughbeam photoelectric sensor receiver
Series: | 23 |
Operating principle: | Throughbeam principle |
Device type: | Receiver |
Operating range: | 0 ... 8 m |
Operating range limit: | 0 ... 10 m |
Protective circuit: | Polarity reversal protection, Short circuit protected |
Supply voltage UB: | 10 ... 30 V, DC, Incl. residual ripple |
Residual ripple: | 0 ... 15 %, From UB |
Open-circuit current: | 0 ... 15 mA |
Number of digital switching outputs: | 1 Piece(s) |
Switching element: | Transistor, NPN |
Switching principle: | Light switching |
Switching frequency: | 500 Hz |
Response time: | 1 ms |
Function: | Voltage supply, Signal OUT |
Type of connection: | Cable |
Cable length: | 2,000 mm |
Number of conductors: | 3 -wire |
Dimension (W x H x L): | 11.4 mm x 34.2 mm x 18.3 mm |
Housing material: | Plastic, PC-ABS |
Lens cover material: | Plastic / PMMA |
Net weight: | 50 g |
Ambient temperature, operation: | -40 ... 60 °C |
Degree of protection: | IP 67 |
Protection class: | III |
Certifications: | c UL US |
Standards applied: | IEC 60947-5-2 |
Customs tariff number: | 85365019 |
eCl@ss 8.0: | 27270901 |
eCl@ss 9.0: | 27270901 |
ETIM 5.0: | EC002716 |
ETIM 6.0: | EC002716 |
ТН ВЭД: | |
Страна происхождения: | China |
EAN: | |
Вес: | 0,05 kg |
Длина: | 0,00 m |
Ширина: | 0,00 m |
Высота: | 0,00 m |
