50135000
DCR50M2/R2
DCR50M2/R2 - Stationary 2D-code reader
Series: | DCR 50 |
Special version: | Scan Engine Module |
Software functions: | Reading of 2D codes, Reading of 1D codes |
Code types, readable: | Pharma Code, 2/5 Interleaved, Australian Post, Aztec, Canada Post, Codabar, Codablock F, Code 11, Code 128, Code 32, Code 39, Code 49, Code 93, Data Matrix Code, EAN/UPC, GS1 Composite, GS1 Databar, Intelligent Mail, Japan Post, KIX Code, Korea Post, Maxicode, Micro PDF, Micro QR, MSI Plessey, PDF417, Planet, Postnet, QR code, Telepen, UK Royal Mail, UPU ID Tags |
Reading distance: | 30 ... 425 mm |
Camera resolution, horizontal: | 1,280 px |
Camera resolution, vertical: | 960 px |
Modulus size: | 0.127 ... 0.528 mm |
Supply voltage UB: | 4.75 ... 5.25 V, DC |
Current consumption, max.: | 300 mA |
Number of digital switching inputs: | 1 Piece(s) |
Number of digital switching outputs: | 1 Piece(s) |
Voltage type: | DC |
Switching element: | Transistor, NPN |
Type: | RS 232 |
Function: | Process |
Transmission speed: | 9,600 ... 115,200 Bd |
Data format: | Adjustable |
Number of connections: | 1 Piece(s) |
Function: | Data interface, Configuration interface, Signal IN, Signal OUT, Voltage supply |
Type of connection: | Molex connector |
No. of pins: | 6 -pin |
Type: | Male |
Design: | Cubic |
Dimension (W x H x L): | 31.6 mm x 12.7 mm x 27.5 mm |
Housing material: | Plastic, Metal |
Net weight: | 10 g |
Housing color: | Silver |
Type of fastening: | Mounting thread |
Type of display: | Buzzer, LED |
Type of configuration: | Software |
Ambient temperature, operation: | 0 ... 50 °C |
Ambient temperature, storage: | -20 ... 60 °C |
Relative humidity (non-condensing): | 10 ... 90 % |
Customs tariff number: | 84719000 |
eCl@ss 8.0: | 27280103 |
eCl@ss 9.0: | 27280103 |
ETIM 5.0: | EC002999 |
ETIM 6.0: | EC002999 |
ТН ВЭД: | |
Страна происхождения: | Malaysia |
EAN: | |
Вес: | 0,02 kg |
Длина: | 0,00 m |
Ширина: | 0,00 m |
Высота: | 0,00 m |
