Продукт
Leuze electronic
50132136
LCAM 408i C7F-XX
Сделать запрос
Авторское право на изображение: Leuze electronic
Leuze electronic 50132136
LCAM 408i C7F-XX
LCAM 408i C7F-XX - Camera
По запросу. Пожалуйста, отправьте нам письмо, чтобы узнать цену и наличие.
"ucnguBrctvdgcxgt0eqo"
Описание
Технические характеристики
| Series: | LCAM |
| Suitable for: | Use of cleaning agents |
| Chip: | CMOS |
| Software functions: | Image transfer |
| Working range: | 1,000 ... 5,000 mm |
| Camera resolution, horizontal: | 2,592 px |
| Camera resolution, vertical: | 1,944 px |
| Focal length: | 4 mm |
| Chip size: | 1/2.5 in |
| Frame rate (images per second), max.: | 53 pieces per second |
| Camera type: | Color |
| Supply voltage UB: | 18 ... 30 V, DC |
| Power consumption, max.: | 3.6 W |
| Type: | Ethernet |
| Address assignment: | Manual address assignment, DHCP |
| Transmission speed: | 100 Mbit/s, 1 Gbit/s, 10 Mbit/s |
| Function: | Service, Process |
| Switch functionality: | None |
| Transmission protocol: | TCP/IP , RTP/RTSP |
| Function: | Service interface, Configuration interface, Data interface |
| Type of connection: | Connector |
| Designation on device: | SERVICE |
| Thread size: | M12 |
| No. of pins: | 8 -pin |
| Encoding: | X-coded |
| Function: | Voltage supply |
| Type of connection: | Connector |
| Designation on device: | PWR |
| Thread size: | M12 |
| No. of pins: | 4 -pin |
| Encoding: | A-coded |
| Dimension (W x H x L): | 75 mm x 55 mm x 113 mm |
| Housing material: | Metal, Diecast aluminum |
| Lens cover material: | Glass |
| Net weight: | 411 g |
| Ambient temperature, operation: | -30 ... 70 °C |
| Ambient temperature, storage: | -30 ... 70 °C |
| Degree of protection: | IP 67, IP 65 |
| Customs tariff number: | 84733080 |
| eCl@ss 8.0: | 27310201 |
| eCl@ss 9.0: | 27310201 |
| ETIM 6.0: | EC001511 |
Логистические характеристики
| ТН ВЭД: | |
| Страна происхождения: | Deutschland |
| EAN: | |
| Вес: | 0,52 kg |
| Длина: | 0,00 m |
| Ширина: | 0,00 m |
| Высота: | 0,00 m |
