750330
PNOZ s30 24-240VACDC 2 n/o 2 n/c
PNOZsigma Safety relay (standalone). Outputs: 2 N/O, 2 N/C, UB 24 -. 240 V AC/DC, width: 45 mm Speed-, standstill monitor of the PNOZsigma, product group, proximity switch and/or incremental encoder, display, operation Push & Turn, Plug-in terminals of screw type, expansion with. PNOZsigma Contact expansion.
Certifications:: | CE, cULus Listed, EAC (Eurasian), TÜV, CCC |
Application options:: | Speed monitoring, Standstill monitoring |
Operating modes:: | Single-channel, Automatic reset, Dual-channel, Manual reset, Monitored manual reset |
Standards:: | EN 1088, EN 60204-1, EN 62061, EN ISO 10218-1, EN ISO 13849-1, VDI 2854 |
Supply voltage (V):: | 24,0 - 240,0 |
Supply voltage type:: | AC/DC |
Terminal type:: | Screw terminal |
Max. current at DC13 I (6 cycles/min):: | 4.0 A |
Width dimension:: | 45.0 mm |
Height dimension:: | 98.0 mm |
Depth dimension:: | 120.0 mm |
Gross weight:: | 425 g |
Net weight:: | 405 g |
Ambient temperature:: | -20 - 55 °C |
ECCN: | |
Kraj pochodzenia: | |
EAN: | |
Waga: | 0,00 kg |
Długość: | 0,00 m |
Szerokość: | 0,00 m |
Wysokość: | 0,00 m |
