680935
NX-TC3407
4 loops, Thermocouple/Pt100 input, PNP 8 Digital Outputs 24 VDC, 21 mA/point, Heat and Cool control, Push-in Plus terminals
I/O system: | NX I/O Bus |
Type of module: | Temperature control |
Number of digital inputs: | 0 |
Digital input type: | None |
Number of digital outputs: | 8 |
Digital output type: | PNP, PWM |
Number of analog inputs: | 4 |
Temperature input type: | B, C (WRe5-26), E, J, JPt100, K, L, N, P (PLII), Pt100, R, S, T, U |
Linear analog input type: | None |
Input circuit type: | Isolated |
Number of analog outputs: | 0 |
Linear analog output type: | None |
Conversion time: | 50 ms/unit |
Signal processing: | Free running |
Control function: | Heat and cool |
Heater burnout detection: | |
IO link master: | |
I/O connection type: | Push-in |
Number of I/O connectors: | 2 |
Detachable I/O connector: | |
SIL according to IEC 61508: | None |
Degree of protection (IP): | IP20 |
Height: | 100 mm |
Width: | 24 mm |
Depth: | 71 mm |
Product Weight (unpacked): | 140 g |
ECCN: | |
Kraj pochodzenia: | China |
EAN: | 4549734191449 |
Waga: | 0,00 kg |
Długość: | 0,00 m |
Szerokość: | 0,00 m |
Wysokość: | 0,00 m |
