Leuze electronic
50132998
MSI-EM-IO84NP-03
Poproś o ofertę
Prawa autorskie do obrazu: Leuze electronic
Leuze electronic 50132998
MSI-EM-IO84NP-03
MSI-EM-IO84NP-03 - Non-safe I/O module
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
Parametry techniczne
| Series: | MSI-EM |
| Application: | Processing of non-safe signals |
| Number of safe I/Os: | 4 IN, 4 OUT, 4 programmable I/O |
| Functions: | Non-safe extension module for the MSI 400 configurable safety control, Extension with 4 non-safe inputs, 4 non-safe outputs and 4 non-safe freely programmable I/Os (OSSDs) |
| Mission time: | 20 years, EN ISO 13849-1 |
| Supply voltage UB: | 24 V, DC, -30 ... 25 % |
| Power consumption, max.: | 0.5 W |
| Nominal voltage UN: | 24 V |
| Number of outputs: | 4 Piece(s) |
| Number of configurable inputs/outputs: | 4 Piece(s) |
| Type of digital output: | Transistor |
| Short circuit protection, outputs: | Yes |
| Min. voltage permitted at the output: | 16.2 V |
| Max. voltage permitted at the output: | 30 V |
| Total output current, max.: | 4 A |
| Nominal output current per output, max.: | 0.5 A |
| Number of inputs: | 4 Piece(s) |
| Voltage permitted at the input: | 30 V |
| Input current at signal 1: | 3 mA |
| Type: | Internal bus (SBUS+) |
| Number of connections: | 1 Piece(s) |
| Function: | Signal IN, Signal OUT, Voltage supply |
| Type of connection: | Terminal |
| Type of terminal: | Spring-cage terminal |
| No. of pins: | 16 -pin |
| Connection cross sections: | 2 x 0.2 to 1.5 mm², wire, 2 x 0.2 to 1.5 mm², wire, 2 x 0.25 to 1.5 mm², wire with wire-end sleeve (pressed in trapezium shape) |
| Dimension (W x H x L): | 22.5 mm x 107 mm x 120.8 mm |
| Net weight: | 180 g |
| Housing color: | Gray |
| Type of fastening: | Snap-on mounting |
| Ambient temperature, operation: | -25 ... 65 °C |
| Ambient temperature, storage: | -25 ... 70 °C |
| Relative humidity (non-condensing): | 10 ... 95 % |
| Degree of protection: | IP 20 (terminals), IP 40 (housing) |
| Protection class: | III |
| Certifications: | c UL US |
| Vibration resistance: | 5 ... 150 Hz |
| Test procedure for oscillation in accordance with standard: | EN 60068-2-6 |
| Shock resistance, single shock: | 30 g, 11 ms, EN 60068-2-27 |
| Customs tariff number: | 85371091 |
| eCl@ss 8.0: | 27242204 |
| eCl@ss 9.0: | 27242204 |
| ETIM 5.0: | EC001419 |
| ETIM 6.0: | EC001419 |
Parametry logistyczne
| ECCN: | |
| Kraj pochodzenia: | Deutschland |
| EAN: | |
| Waga: | 0,20 kg |
| Długość: | 0,00 m |
| Szerokość: | 0,00 m |
| Wysokość: | 0,00 m |
