50126493
GF-ETG-SS-710-SU
GF-ETG-SS-710-SU - Glass fiber optics type diffuse reflective
Series: | GF |
Operating principle: | Diffuse reflection principle |
Area of application: | General applications |
Special version: | Heat resistant |
Opening angle: | 65 ° |
Light beam exit: | bent 90° |
Fastening of the probe: | Ø 4.5 mm |
Smallest bending radius (static): | R40 |
Outer diameter: | 6 mm |
Head material: | Stainless steel |
Type: | Glass fiber optics (GF) |
Fiber length: | 1,000 mm |
Fiber sheathing material: | Stainless steel |
ETIM 6.0: | EC002651 |
Smallest bending radius (static): | R40 |
Smallest bending radius (moving): | R40 |
Sleeve length at optical outlet: | 5 mm |
Metric thread on fiber optic sleeve: | No |
Ambient temperature, operation: | -30 ... 300 °C |
Customs tariff number: | 90011090 |
eCl@ss 8.0: | 27270905 |
eCl@ss 9.0: | 27270905 |
ETIM 5.0: | EC002651 |
ETIM 6.0: | EC002651 |
ECCN: | |
Kraj pochodzenia: | Deutschland |
EAN: | |
Waga: | 0,08 kg |
Długość: | 0,00 m |
Szerokość: | 0,00 m |
Wysokość: | 0,00 m |
