Article image 50126395

Leuze electronic 50126395

CML720i-T10-1260.A-M12-EX

CML720i-T10-1260.A-M12-EX - Light curtain transmitter

Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"

Opis

Parametry techniczne

Series: 720
Operating principle: Throughbeam principle
Device type: Transmitter
Contains: 2x BT-NC sliding block
Application: Object measurement
Special version: Crossed-beam scanning, Diagonal-beam scanning, Ex-protected, Parallel-beam scanning
Operating range: 0.3 ... 7 m
Measurement field length: 1,260 mm
Number of beams: 124 Piece(s)
Beam spacing: 10 mm
Light source: LED, Infrared
Minimum object diameter: 20 mm
Supply voltage UB: 18 ... 30 V, DC
Cycle time: 4.24 ms
Number of connections: 1 Piece(s)
Plug outlet: Axial
Function: Sync-input, Connection to receiver, Voltage supply
Type of connection: Connector
Thread size: M12
Material: Metal
No. of pins: 5 -pin
Dimension (W x H x L): 30.7 mm x 40.3 mm x 1,293 mm
Housing material: Metal, Aluminum
Lens cover material: Plastic
Type of display: LED
Ambient temperature, operation: -30 ... 60 °C
Ex-Zone: 2, 22
Ex device group: II
Degree of protection: IP 65
Protection class: III
Standards applied: IEC 60947-5-2
Customs tariff number: 90314990
eCl@ss 8.0: 27270910
eCl@ss 9.0: 27270910
ETIM 5.0: EC002549
ETIM 6.0: EC002549

Parametry logistyczne

ECCN:
Kraj pochodzenia: Deutschland
EAN:
Waga: 1,33 kg
Długość: 0,00 m
Szerokość: 0,00 m
Wysokość: 0,00 m
