AO98A980
Width: | 45mm |
Height: | 84mm |
Length: | 121mm |
Ambient temperature: | 0 - 50°C |
Version: | Expansion device |
Depth: | 121mm |
Housing material: | Plastic |
Number of normally open contacts: | 3 |
Number of outputs, safety-related, undelayed, with contact: | 3 |
Type of electrical connection: | Screw connection |
With muting function: | yes |
Voltage type for actuation: | DC |
No-load current: | 170mA |
With start input: | yes |
Switching voltage: | 250 |
Rated control supply voltage Us at DC: | 24 - 24V |
Rated switching current: | 3A |
Evaluation of inputs: | Dual channel |
Category in acc. with EN 954-1: | 4 |
Suitable for cycle operation: | yes |
eClass 7.0: | 27371819 |
eClass 7.1: | 27371819 |
eClass 8.0: | 27371819 |
eClass 9.0: | 27371819 |
eClass 9.1: | 27371819 |
ETIM-6.0: | EC001449 |
ETIM-7.0: | EC001449 |
IPF Product Group: | 700 |
shipping weight: | 0.44kg |
packaging dimensions: | 145.0mm x 65.0mm x 170mm |
customs tariff number: | 85364190 |
ECCN: | |
Kraj pochodzenia: | |
EAN: | |
Waga: | 0,00 kg |
Długość: | 0,00 m |
Szerokość: | 0,00 m |
Wysokość: | 0,00 m |
