BC9050
BC9050 | Ethernet TCP/IP Bus Terminal Controller
The BC9050 “Compact” Bus Terminal Controller with compact housing is a Bus Coupler with integrated PLC functionality and has a fieldbus interface for Ethernet. It is an intelligent slave that can be used as a non-central intelligence in the Ethernet system. One unit consists of the Bus Terminal Controller, any number of terminals between 1 and 64, and a bus end terminal. With the K-bus extension, up to 255 Bus Terminals can be connected.
Programming: | via TwinCAT and programming interface or Ethernet |
Program memory: | 48 kbytes |
Data memory: | 32 kbytes |
Remanent data: | 2 kbytes |
Runtime system: | 1 PLC task |
PLC cycle time: | approx. 1.5 ms for 1,000 instructions (without I/O cycle, K-bus) |
Programming languages: | IEC 61131-3 (IL, LD, FBD, SFC, ST) |
Online change: | yes |
ECCN: | |
Kraj pochodzenia: | |
EAN: | |
Waga: | 0,00 kg |
Długość: | 0,00 m |
Szerokość: | 0,00 m |
Wysokość: | 0,00 m |
