ABB 2CDG120067R0011

BCM/S6.5.5.1

BCM/S6.5.5.1 BAC Module, 4 Analogue Inputs and 2 Analogue Outputs

Opis

Extension module for the BAC/S Building Automation Controller KNX with 4 analog inputs and 2 analog outputs. The inputs and outputs support voltage signals from 0 V .. + 10 V, 0 V .. + 5 V, -2.5 V .. + 2.5 V and -5 V .. + 5 V as well as current signals of 0 mA .. 20 mA and 4 mA .. 20 mA. Connection of the cables via pluggable spring terminals.
