Producto
Omron
680541
NX-TC2408
Solicitar una oferta
Derechos autor imagen: Omron
Omron 680541
NX-TC2408
2 lazos, entrada Pt100/termopar, 2 salidas analógicas, 4 - 20 mA, resolución 1:10000, control de calor o frío, terminales Push-in Plus
Bajo pedido. Envíenos un correo electrónico para consultar el precio y la disponibilidad.
"ucnguBrctvdgcxgt0eqo"
Descripción
Parámetros técnicos
| I/O system: | NX I/O Bus |
| Type of module: | Temperature control |
| Number of digital inputs: | 0 |
| Digital input type: | None |
| Number of digital outputs: | 0 |
| Digital output type: | None |
| Number of analog inputs: | 2 |
| Temperature input type: | B, C (WRe5-26), E, J, JPt100, K, L, N, P (PLII), Pt100, R, S, T, U |
| Linear analog input type: | None |
| Input circuit type: | Isolated |
| Number of analog outputs: | 2 |
| Linear analog output type: | 0 to 20 mA, 4 to 20 mA |
| Resolution of the analog outputs: | 14 Bit |
| Conversion time: | 50 ms/unit |
| Signal processing: | Free running |
| Control function: | Heat or cool |
| Heater burnout detection: | |
| IO link master: | |
| I/O connection type: | Push-in |
| Number of I/O connectors: | 1 |
| Detachable I/O connector: | |
| SIL according to IEC 61508: | None |
| Degree of protection (IP): | IP20 |
| Height: | 100 mm |
| Width: | 12 mm |
| Depth: | 71 mm |
| Product Weight (unpacked): | 75 g |
Parámetros logísticos
| ECCN: | |
| País de origen: | China |
| EAN: | 4549734191418 |
| Peso: | 0,00 kg |
| Longitud: | 0,00 m |
| Anchura: | 0,00 m |
| Altura: | 0,00 m |
