7760056306
DRI314110L
Type: | DRI314110L |
Order No.: | 7760056306 |
Version: | D-SERIES DRI, Relay, Number of contacts: 1, CO contact AgSnO, Rated control voltage: 110 V DC, Continuous current: 10 A, Flat blade connections (4.7 mm x 0.5 mm) |
GTIN (EAN): | 6944169740114 |
Qty.: | 20 pc(s). |
Width: | 13 mm |
Width (inches): | 0.512 inch |
Height: | 31 mm |
Height (inches): | 1.22 inch |
Depth: | 28 mm |
Depth (inches): | 1.102 inch |
Net weight: | 19 g |
Humidity: | 35...85 % rel. humidity, no condensation |
Operating temperature, max.: | 55 °C |
Operating temperature, min.: | -40 °C |
Storage temperature, max.: | 85 °C |
Storage temperature, min.: | -40 °C |
Operating temperature: | -40 °C...55 °C |
Storage temperature: | -40 °C...85 °C |
REACH SVHC: | Lead 7439-92-1 |
Certificate No. (cURus): | E312083 |
Rated control voltage: | 110 V DC |
Rated current DC: | 4,8 mA |
Power rating: | 530 mW |
Pull-in/drop-out voltage, typ.: | 82.5 V / 16.5 V DC |
Coil resistance: | 22800 Ω ± 10 % |
Status indicator: | Green LED |
Rated switching voltage: | 250 V AC |
Max. switching voltage, AC: | 250 V |
Max. switching voltage, DC: | 250 V |
Continuous current: | 10 A |
AC switching capacity (resistive), max.: | 2500 VA |
DC switching capacity (resistive), max.: | 240 W @ 24 V |
Switch-on delay: | ≤ 15 ms |
Switch-off delay: | ≤ 10 ms |
Min. switching power: | 10 mA @ 12 V, 100 mA @ 5 V |
Max. switching frequency at rated load: | 0.1 Hz |
Contact type: | 1 CO contact (AgSnO) |
Test button: | No |
Mechanical switch position indicator: | No |
Colour: | Transparent |
UL 94 flammability rating: | V-2 |
Rated voltage: | 300 V |
Surge voltage category: | III |
Pollution severity: | 2 |
Insulating material group: | IIIa |
Protection degree: | IP20 |
Creepage and clearance distance input – output: | ≥ 4 mm |
Impulse withstand voltage: | 5 kV (1.2/50 µs) |
Standards: | IEC 61810-1, EN 60664-1:2007, EN 61000-6-2:2005, EN 61000-6-4:2007 + A1:2011, UL 508 |
Certificate No. (cURus): | E312083 |
Wire connection method: | Flat blade connections (4.7 mm x 0.5 mm) |
ETIM 6.0: | EC001437 |
ETIM 7.0: | EC001437 |
eClass 9.0: | 27-37-16-01 |
eClass 9.1: | 27-37-16-01 |
eClass 10.0: | 27-37-16-01 |
ROHS: | Conform |
Type: | DRI314110L |
Order No.: | 7760056306 |
Version: | D-SERIES DRI, Relay, Number of contacts: 1, CO contact AgSnO, Rated control voltage: 110 V DC, Continuous current: 10 A, Flat blade connections (4.7 mm x 0.5 mm) |
GTIN (EAN): | 6944169740114 |
Qty.: | 20 pc(s). |
Width: | 13 mm |
Width (inches): | 0.512 inch |
Height: | 31 mm |
Height (inches): | 1.22 inch |
Depth: | 28 mm |
Depth (inches): | 1.102 inch |
Net weight: | 19 g |
Humidity: | 35...85 % rel. humidity, no condensation |
Operating temperature, max.: | 55 °C |
Operating temperature, min.: | -40 °C |
Storage temperature, max.: | 85 °C |
Storage temperature, min.: | -40 °C |
Operating temperature: | -40 °C...55 °C |
Storage temperature: | -40 °C...85 °C |
REACH SVHC: | Lead 7439-92-1 |
Certificate No. (cURus): | E312083 |
Rated control voltage: | 110 V DC |
Rated current DC: | 4,8 mA |
Power rating: | 530 mW |
Pull-in/drop-out voltage, typ.: | 82.5 V / 16.5 V DC |
Coil resistance: | 22800 Ω ± 10 % |
Status indicator: | Green LED |
Rated switching voltage: | 250 V AC |
Max. switching voltage, AC: | 250 V |
Max. switching voltage, DC: | 250 V |
Continuous current: | 10 A |
AC switching capacity (resistive), max.: | 2500 VA |
DC switching capacity (resistive), max.: | 240 W @ 24 V |
Switch-on delay: | ≤ 15 ms |
Switch-off delay: | ≤ 10 ms |
Min. switching power: | 10 mA @ 12 V, 100 mA @ 5 V |
Max. switching frequency at rated load: | 0.1 Hz |
Contact type: | 1 CO contact (AgSnO) |
Test button: | No |
Mechanical switch position indicator: | No |
Colour: | Transparent |
UL 94 flammability rating: | V-2 |
Rated voltage: | 300 V |
Surge voltage category: | III |
Pollution severity: | 2 |
Insulating material group: | IIIa |
Protection degree: | IP20 |
Creepage and clearance distance input – output: | ≥ 4 mm |
Impulse withstand voltage: | 5 kV (1.2/50 µs) |
Standards: | IEC 61810-1, EN 60664-1:2007, EN 61000-6-2:2005, EN 61000-6-4:2007 + A1:2011, UL 508 |
Certificate No. (cURus): | E312083 |
Wire connection method: | Flat blade connections (4.7 mm x 0.5 mm) |
ETIM 6.0: | EC001437 |
ETIM 7.0: | EC001437 |
eClass 9.0: | 27-37-16-01 |
eClass 9.1: | 27-37-16-01 |
eClass 10.0: | 27-37-16-01 |
ROHS: | Conform |
ECCN: | |
Country of Origin: | |
EAN: | |
Weight: | 0.021 kg |
Length: | 0.00 m |
Width: | 0.00 m |
Height: | 0.00 m |
