Product
Rechner Sensors
XA0065
Request a Quote
Image copyright: Rechner Sensors
Rechner Sensors XA0065
KXA-5-1MINI-B-P-A-ET-Z02-Y90
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Evaluation unit with EasyTeach by Wire (ETW) & EasyTeach by Magnet (ETM). Capacitive evaluation units. Series KXA-eXtreme. Housing 46,6 x 74,5 x 30 mm. KXA-…-MINI for connection to capacitive sensors KXS-…-M5/… to -M16/…. Adjustable with EasyTeach by Wire / EasyTeach by Magnet (ETM)
Downloads
Technical parameters
| Thread / Process connection: | 75 x 47 x 44 mm |
| Housing material: | PA |
| Electrical version: | 4-Leiter DC |
| Operating current (Ie): | 0…250 mA pro Ausgang |
| Voltage drop max. (Ud): | ≤ 2,5 V |
| Permitted residual ripple max.: | 40% |
| Noload current (Io): | Typ. 50 mA |
| Frequency of operating cycles max.: | 50 Hz |
| LEDdisplay: | Grün / Gelb |
| Protective circuit: | Eingebaut |
| Degree of protection IEC 60529: | IP 65 |
| Norm: | EN 60947-5-2 |
| Operating voltage: | 18…36 V DC |
| Permitted ambient temperature min.: | -25 °C |
| Permitted ambient temperature max.: | +55 °C |
| Output function: | Antivalent (S + Ö) |
| Output signal: | NPN |
| Cable length: | 2 m |
| Connection: | PUR-Kabel, 4 x 0,14 mm² |
| CE: | JA |
| RoHS: | JA |
| UL CSA certification: | JA |
| MTTF: | 209,03 Jahre |
| WHG certification: | Auf Anfrage |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
