Product
Rechner Sensors
AF0063
Request a Quote
Image copyright: Rechner Sensors
Rechner Sensors AF0063
KFA-5-4-XXL-P-A-KL-Y50
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Downloads
Technical parameters
| Thread / Process connection: | 120 x 120 x 60 mm |
| Housing material: | ABS |
| Operating current (Ie): | 0…250 mA pro Kanal |
| Permitted residual ripple max.: | 40% |
| Noload current (Io): | Typ. 120 mA |
| Frequency of operating cycles max.: | 4 Hz |
| LEDdisplay: | Grün / Gelb |
| Protective circuit: | Eingebaut |
| Degree of protection IEC 60529: | IP 54 |
| Norm: | EN 60947-5-2 |
| Operating voltage: | 18…36 V DC |
| Permitted ambient temperature min.: | -25 °C |
| Permitted ambient temperature max.: | +55 °C |
| Output function: | Antivalent (S + Ö) |
| Output signal: | PNP |
| Connection: | Schraubklemmen und Buchsen |
| Connection to probe: | Y50 |
| CE: | JA |
| RoHS: | JA |
| UL CSA certification: | JA |
| MTTF: | 124 Jahre |
| WHG certification: | Auf Anfrage |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
