UC10.242
DC-UPS with capacitor storage
Built-in capacitors as energy source. EDLC electrochemical double layer capacitors). Wide temperature range between -40°C and +60°C. Typically >10 Years operational lifetime expectancy. Regulated output voltage in buffer mode. No ventilated cabinets required. No generation of hydrogen as VRLA batteries do). Short charging time, unit is rapidly back in ready mode. Output is decoupled from the input to separate load. Circuits into Buffered and Non-buffered Sections. Supports PC-Mode function
DC-Input Voltage: | DC 24V |
Nominal Voltage: | 24Vdc |
Output Current: | 15A |
Storage element: | Electrochemical Double Layer Capacitors |
Size (WxHxD): | 198mm x 124mm x 117mm |
Weight per Piece (excluding packing): | 1720g |
Operat. Temperature Range: | -40°C ... +60°C |
Mounting Method: | Din-Rail |
MTBF SN 29500 @ 40°C (h): | 850.000h |
Connection method: | spring terminals |
