Product
Puls
CPS20.241-60
Request a Quote
Image copyright: Puls
Puls CPS20.241-60
DC/DC converter
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
EN 50155 Railway compliant. Conformal coated PC-boards. Built-in redundancy (Decoupling MOSFET at the output). Quick-connect spring-clamp terminals. 77-154Vdc Wide-range input. Width only 65mm. Efficiency up to 93.7%. Excellent partial load efficiency. Safe Hiccup. PLUS, overload mode. Minimal inrush current surge. Full power between -40°C and +70°C. DC-OK relay contact. Reverse input polarity protected
Technical parameters
| DC-Input Voltage: | DC 110V (-30%/+40%) |
| Nominal Voltage: | 24.5Vdc |
| Adjustment Range: | 24.5 |
| Output Current Range: | 16.3A |
| Output Current: | 16.3A at 24.5V |
| Output Power: | 400W |
| max. Ripple and Noise Voltage: | 70mVpp |
| Size (WxHxD): | 65mm x 124mm x 127mm |
| Weight per Piece (excluding packing): | 980g |
| Operat. Temperature Range: | -40°C ... +70°C |
| Mounting Method: | DIN-Rail |
| Efficiency, typ.: | 93.7% |
| Power Losses, typ.: | 26.9W |
| MTBF SN 29500 @ 40°C (h): | 571 000h |
| Connection method: | Spring-clamp terminals |
