Image copyright: Omron
Omron 682695
NX-HAD402
4 High Speed Analog Inputs, -10 to 10 V, -5 to 5 V, 0 to 10 V, 0 to 5 V, 1 to 5V, 0 to 20 mA, 4 to 20 mA, differential, resolution 1:64000, 5 µs/ch, screwless push-in connector, 24 mm wide, PNP
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| I/O system: | NX I/O Bus |
| Type of module: | Analog I/O |
| Number of analog inputs: | 4 |
| Temperature input type: | None |
| Linear analog input type: | -10 to 10 V, -5 to 5 V, 0 to 10 V, 0 to 20 mA, 0 to 5 V, 1 to 5 V, 4 to 20 mA |
| Resolution of the analog inputs: | 16 Bit |
| Input circuit type: | Differential |
| Number of analog outputs: | 0 |
| Linear analog output type: | None |
| Resolution of the analog outputs: | 0 Bit |
| Conversion time: | 0.02 ms/unit |
| Signal processing: | High speed, Synchronous |
| IO link master: | |
| I/O connection type: | Push-in |
| Number of I/O connectors: | 2 |
| Detachable I/O connector: | |
| Suitable for safety functions: | |
| Degree of protection (IP): | IP20 |
| Height: | 100 mm |
| Width: | 12 mm |
| Depth: | 71 mm |
| Product Weight (unpacked): | 0 g |
Logistic parameters
| ECCN: | |
| Country of Origin: | China |
| EAN: | 4549734209663 |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
