8009729
EKP4SP
Receptacle, Ø8mm snap female, straight, print contact, 4 poles
Connector: | female, Ø8mm snap |
Number of pins: | 4 |
Rated voltage: | 60V |
Current load (at 40°C): | 4 |
Insulation resistance (Ω): | ≥10 8 |
Ambient temperature product: | -30°C...+90°C |
Contact material: | Metal, CuZn, gold-plated |
Contact-carrier material: | Plastic, PA, BK |
Connecting type: | Print contact |
Standards: | IEC 61076-2-104 |
Degree of protection (mounted): | IP65, IP67 |
Mechanical life-cycle: | >100 mating cycles |
Degree of pollution: | 3/2 |
ECCN: | |
Country of Origin: | Deutschland |
EAN: | |
Weight: | 0.00 kg |
Length: | 0.00 m |
Width: | 0.00 m |
Height: | 0.00 m |
