1SVR740720R1400
CM-MSS.11P
CM-MSS.11P Therm. motor protec. relay 1n/o+1n/c, 24-240VAC/DC
The CM-MSS.11P belongs to the CM-MSS thermistor motor protection relay range. It operates with a rated control supply voltage of 24 - 240 V AC / DC and has a 1 n/c + 1 n/o (SPDT) output with contacts rated at 250 V / 4 A. It features one sensor circuit to monitor PTC temperature sensors and works according to the closed-circuit principle. The sensor circuit of the CM-MSS.11P is interrupted-wire monitored and the relay will be reset automatically after the failure has been removed. This protection relay is certified according to the ATEX directive 94/9/EC. A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers maintenance free Easy Connect Technology with push-in terminals.
ECCN: | |
Country of Origin: | DE |
EAN: | |
Weight: | 0.12 kg |
Length: | 0.1037 m |
Width: | 0.0225 m |
Height: | 0.0856 m |
